Three-step defibrillation process
Two-button operation
Extensive voice and visual prompts for the operator
Continuous event recording for reporting each use to a printer or computer
Weekly self-test to ensure readiness
| Waveform | Biphasic Truncated exponential |
|---|---|
| Energy Sequence | 150, 150, 200-Joules Max : 200-Joules |
| Charge Time | 8 sec. to 150 J 10 sec. to 200 J (NEW battery) |
| Analysis time | 9 sec |
| Alarm | LED and voice prompts |
| Control | Power On/Off key Deliver shock key |
| Accuracy | ±15 % into impendance from 25 to 75 Ω |
| Restricted impedance | 20 Ω to 200 Ω |
| Battery type | Non-Rechargeable: 12V DC. 3.0 Ah |
| Battery capacity | 100 discharges at 200 Joules or 120 discharges at 150 Joules |
| Dimensions | 303 X 216 X 89 mm |
| Weight | 2 kgs |
Three-step defibrillation process
Two-button operation
Extensive voice and visual prompts for the operator
Continuous event recording for reporting each use to a printer or computer
Weekly self-test to ensure readiness
Biphasic energy output
Lock-out protection to prevent inadvertent defibrillation
