Accurate contour technology
Distortion-free mechanical scanning
4D array scan
High speed scan
Wireless operation
Specifications
| Ultrasonic probe | 2.6 MHz Mechanical scan |
|---|---|
| Screen | 8-inch TFT color LCD |
| Measuring range | 999 ml |
| Accuracy | 0 ml ≤ V ≤ 999 ml ± 15% |
| Sway angle | 120° ± 2° |
| Rotating angle | 180° ± 2° |
| Scan depth | ≥140 mm |
| Module volume | 128 ± 10ml |
| Printer | For micro characters, graphics and images |
| Interface | USB interface |
| Battery | Voltage 7.4V Capacity: ≥5200mAh Sustainable use for 4.5 hours Charge for 3.5 ~ 4 hours full |
| Dimension | 320 x 180 x 65 mm |
| Weight | 1.8 kgs |
Features
Accurate contour technology
Distortion-free mechanical scanning
4D array scan
High speed scan
Wireless operation
High recognition rate for bladder wall
Measurement irrespective of bladder shape and size
High precision rotary encoder, precise positioning
Waterproof probe
