15-inch LED display
Progressive SMT component
Dynamic signal reception focal point
High-accuracy DSC image formation
Backlit silicon keyboard with navigation scroll
Intelligent TGC gain control
Automated report generation
Specifications
| Monitor | 15 inch LCD screen |
|---|---|
| TGC | 0-99, 8-segment TGC |
| Focus | 4 |
| Probe Depth | 110 mm |
| Image storage | 127 |
| Image processing | THI, speckle-reduction, color coder, frame averaging, micro- angle adjustment, wall filter, 256 grey scale, scanning angle/width control, |
| Display mode | B, BB,4B,BM,PW,CW |
| Output interface | SVGA (SVGA color monitor), PAL-D |
| Resolution | Lateral resolution ≤2mm (depth≤80mm) ≤3mm (80< depth≤130mm) Axial resolution ≤1mm (depth≤80mm) ≤ 2mm (80< depth≤130mm) |
| Geometry precision | lateral≤5% ,axial≤5% |
| Pseudo color | 16 |
| Dynamic range | 0 ~ 120 dB |
| Cine loop | 256 frames |
| Body mark | 65 |
| Image reversal | up/down, left/right, black/white |
| Measurement modules | Distance, perimeter, area, heart rate, OB-GYN list (BPD, CRL, GS, FL, HC, AC) |
| Transducers | Convex probe,trans-vaginal probe, trans-rectal probe, high frequency linear probe , visual artificial abortion probe |
| Battery backup time | 4-6 hours |
| Accessories | Standard : 3.5MHz Multi-frequency convex probe(2.5MHz-5.0MHz) Optional : 6.5MHz Trans-vaginal probe(5.5MHz-7.5MHz) 7.5MHz High frequency linear probe(6.5MHz-8.5MHz) |
Features
