Medical Equipment Expert
10.4’ color HD color LED monitor
Temperature display calibration block
Daily Calibration: automatic calibrating after power on
Date analysis: Intelligent real-time data analysis system
Temperature control: Perspex sample with temperature instructions
Specifications
| Measurement parts | Radius and Tibia |
|---|---|
| Measurement mode | double emission and double receiving |
| Measurement parameters | Speed of sound (SOS) BQI (Bone quality Index) T- Score Z-Score RRF (Relative Fracture Risk) |
| Measurement Accuracy | ≤ 0.25% |
| Measurement time | <25 seconds |
| Probe frequency | 1.20MHz |
| Calibration (correction) | Auto-calibration at Power-On |
| Report output | A4, 16K, B5 and more size report |
| Probe spacing | Axial angle, Horizontal Angle, Direction Angle between the probe and the bone plane, real-time angle data |
| Memory | 4GB Memory |
| Power supply | AC power supply: 220 V / 50 Hz Power > 60 W |
| Monitor | 10.4 inch color HD color LED monitor |
| Weight | 4 kgs |
Features
10.4’ color HD color LED monitor
Temperature display calibration block
Daily Calibration: automatic calibrating after power on
Date analysis: Intelligent real-time data analysis system
Temperature control: Perspex sample with temperature instructions
