15-inch LED display
Black and white ultrasound system
96 array elements
Progressive SMT component
Backlit silicon keyboard with navigation scroll
| Monitor | 15-inch LED screen |
|---|---|
| Probe depth | 0-242 mm |
| Scanning mode | Convex / Linear / Micro-convex |
| Display mode | B, B+B, 4B, B+M, M |
| Output interface | SVGA (SVGA color monitor), PAL-D |
| Blind zone | ≤ 3mm |
| Resolution | lateral ≤ 2 mm, axial ≤ 1 mm |
| Geometry precision | latera l≤ 5 % ,axial ≤ 5% |
| Pseudo color | 7 |
| Dynamic range | 0 dB ~ 120 dB |
| Cine loop | 256 frames |
| Body mark | 30 |
| Image reversal | up/ down, left / right, black / white conversion, edge enhancement, gamma correction, frame correlation, pseudo color processor( need external color display). |
| Transducers | Support multiple probes: abdomen, heart, small organ, cavity probe, rectum probe |
| Physical Characteristics | Dimensions: 850 x 650 x 990 mm |
| Accessories | Standard : 3.5MHz Multi-frequency convex probe(2.5MHz ~ 5.0MHz) 7.5MHz High frequency linear probe |
| Optional | Trans-vaginal probe Rectal probe Micro-convex probe |
15-inch LED display
Black and white ultrasound system
96 array elements
Progressive SMT component
Backlit silicon keyboard with navigation scroll
Intelligent TGC gain control
Automated report generation
