Medical Equipment Expert
128 element probe
19" LED displayer
backlight silica gel keyboard
4 active probe connectors
Powerful information management
Specifications
| Monitor | 19-inch LED monitor |
|---|---|
| Imaging mode | Color doppler imaging mode Power doppler mode Real-time triplex mode |
| Imaging functions | Tissue Harmonic Imaging CW: Continuous Wave Doppler B/C/D three synchronize real-time imaging |
| Probe depth | ≥ 300 mm |
| Scanning mode | Convex / Linear / Micro-convex |
| Display mode | B, 2B, 4B, left&right, B|M, B|D, PW, M, B mode, part zoom, B|C|D, B|C|M, B|C, duplex, PW, CFM, CPA |
| Output interface | PAL |
| Blind zone | ≤ 5mm |
| Resolution | Lateral resolution: ≤ 1mm (depth ≤ 80 mm) ≤ 2mm (80 ≤ depth ≤ 130mm). Vertical resolution: ≤1mm(depth≤ 80 mm) ≤2mm(80≤depth≤130mm) |
| Geometry precision | Horizontal ≤ 10%. Longitudinal ≤ 10%. |
| Cine loop | operated automatically and manually |
| Transducers | Convex probe Linear probe Trans-vaginal probe Phased array probe Micro convex probe Rectal probe |
| Physical Characteristics | Dimensions: 870 x 660 x 130 mm |
| Accessories | Main unit, 3.5MHz Multi-frequency convex probe(2.0, 3.0, 3.5, 4.0,5.5MHz), linear probe 19" LED monitor, USB port |
| Optional | High frequency transvaginal probe Microconvex probeh Video/Thermal printer, Laser printer |
Features
128 element probe
19" LED displayer
backlight silica gel keyboard
4 active probe connectors
Powerful information management
Complete application software
