Full-cast anti-corrosive 304 stainless steel frame
X-ray translucent tabletop for radiographic access
Medical grade polyurethane upholstery conforms with safety standards
Electro-hydraulic drive for various functional movements
Gearless hydraulic elevation mechanism assures smooth transition
Performs noiseless operation
Smooth table motion
T shape base design ensures shock resistance and stability
Smooth exterior, easy to clean and disinfect
Qty:
Specifications
| Length | 1960 mm |
|---|---|
| Width | 480 mm |
| Elevation(Vertical) | 750 mm / 950 mm |
| Trendelenburg | ≥ 22° |
| Reverse Trendelenburg | ≥ 15° |
| Lateral Tilt(Horizontal) | 15° / 15° |
| Head Rest(Vertical) | 45° / 90° |
| Footplate | Vertical 90° Horizontal 90° |
| Back plate(Vertical) | 75°/20° |
| Load capacity | 200 kgs |
| Power | 220 V, 50 Hz Output: 1 kW |
| Dimensions | 1960 × 480 × (750 -950) mm |
| Accessories | 1 Anaesthetic screen 2 Shoulder rest 2 Arm support 2 Waist suppport 2 Knee crutch 2 Foot plate 2 Long slider |
