Adopts the foot-stepping hydraulic pressure pump
Threadlike pole drive
X-ray translucent Tabletop for radiographic imaging
Frame design promotes access for C-arm during surgical procedures
Reliable orientation strucutre
Compact and reasonable structure
Specifications
| Length | 2000 mm |
|---|---|
| Width | 500 mm |
| Elevation(Vertical) | 700 mm ~ 1000 mm |
| Trendelenburg | ≥20° |
| Reverse Trendelenburg | ≥20° |
| Lateral Tilt(Horizontal) | 15° / 15° |
| Head Rest(Vertical) | ≥90°/≥90° |
| Footplate | ≥90° |
| Back plate(Vertical) | 65° |
| Load capacity | 350 kgs |
Features
