Hydraulic drive for various table configuration movements
Anti-corrosive 304 stainless steel frame
X-ray translucent tabletop for radiographic access
Performs noiseless operation
Base ensures impact resistance and stability
Smooth exterior, easy to clean and disinfect
Specifications
| Length | 2130 mm |
|---|---|
| Width | 520 mm |
| Elevation(Vertical) | 700 mm ~ 1000 mm |
| Trendelenburg | ≥20° |
| Reverse Trendelenburg | ≥20° |
| Lateral Tilt(Horizontal) | ≥20°/≥20° |
| Head Rest(Vertical) | 30°/-25° |
| Footplate | 90° ~ 180° |
| Back plate(Vertical) | 75°/-15° |
| Load capacity | 200 kgs |
| Power | AC 220 V - 50 Hz |
| Dimensions | 2130 × 520 × (700-1000) mm |
| Accessories | 5 Square clamp I 2 Square clamp II 2 Chest&waist supporters 2 Leg crutches 2 Arm rest 2 Shoulder supporter 1 Supporter |
Features
