Electric hydraulic operation
Hydraulic drive for various functional movements
Performs noiseless operation
Four point electric hydraulic brake
Anti-corrosive 304 stainless steel frame
Smooth table linear and translational movements
Kidney bridge = 110 mm
Smooth exterior, easy to clean and disinfect
Specifications
| Length | 2100 mm |
|---|---|
| Width | 550 mm |
| Elevation(Vertical) | 710 mm ~ 1010 mm |
| Trendelenburg | ≥25° |
| Reverse Trendelenburg | ≥25° |
| Lateral Tilt(Horizontal) | 15° / 15° |
| Head Rest(Vertical) | 40° / 90° |
| Footplate | 15°/90° |
| Back plate(Vertical) | 80°/20° |
| Load capacity | 250 kgs |
| Power | AC 220 V ±10 % V / 50Hz Input power: 600 VA |
Features
