Medical Equipment Expert
7-inch LCD display
Defibrillation : Manual, Synchronized and Asynchronous
Synchronized Mode: Synchronize defibrillator pulse to patient’s R-wave.
Printing method: High-resolution, thermal array print head
Information: Heart rate, Lead/Pads, Alarm
Specifications
| Energy selection | 2, 5,7,10, 20, 30, 50, 70, 100, 150, 200, 300, 360 J |
|---|---|
| Charging time | 3 hours minimum of continuous ECG Monitoring, |
| Display | 7-inch LCD High resolution |
| ECG | Lead selection: Displayed in monitor, paddles, I, II, III, AVR, AVL, AVF, V 3-lead, or 5-lead ECG cable, Heart rate: 20 – 300 BMP Smart Alarms: Beeper/voice prompts indicate shockable rhythm |
| Sweep Speed | 25 mm/sec |
| SpO2 | Measurement Range: 30 – 100 %, +/-2% between 80% - 90%, others +/- 5 % Alarm range: User set high and low limit Alarm Accuracy: +/- 10% within setting values Alarm time Accuracy: less than 12 sec |
| PR | Range: 0bpm ~ 255 bpm |
| Power supply | AC : 100 V ~ 240 V, 50 Hz / 60 Hz Vehicle voltage (option) DC ~ 12 V |
| Alarm | Heart Rate Alarm: On/Off display on monitor, user selectable Smart Alarms: Beeper/voice prompts indicate shockable rhythm |
| AED Mode | Auto analyze and charge x3 with programmable auto energy level selection, screen prompts, and voice prompts Ventricular fibrillation with amplitude = 200 μ Ventricular tachycardia with rates = 140 bpm QRS complex wave duration =140 ms Charge control: control on device front panel, press key on paddle. |
| Battery | Rechargeable, Ni-MH battery, 12V Operation time: For a new, fully charged battery discharges 60 defibrillator. Or 3 hours minimum of continuous ECG Monitoring, Additional parameters affect operating time with different functions. |
| Weight | 12 kgs |
Features
7-inch LCD display
Defibrillation : Manual, Synchronized and Asynchronous
Synchronized Mode: Synchronize defibrillator pulse to patient’s R-wave.
Printing method: High-resolution, thermal array print head
Information: Heart rate, Lead/Pads, Alarm
With pacemaker
Medzer Biphasic Defibrillator feature a high-resolution display screen for clear monitoring during emergencies. They offer versatile defibrillation modes including manual, synchronized, and asynchronous options. The advanced biphasic waveform technology enhances the effectiveness of shock delivery, increasing the chances of restoring normal heart rhythms. Compact and user-friendly, our biphasic defibrillator are designed for rapid response in critical situations.
