Advanced digital processing technology
Parameters: SPO2, ECG, NIBP, TEMP, RESP, PR
72 hours graphic and tabular trends of all parameters
500 NIBP measurement data can be stored and reviewed
Review any patient's information by inputting his ID or name
Apply to internal printer, apply to 3-channals waveform print
High storage memory
Power-off data protection
Built-in large capacity (4400mAh) rechargeable lithium battery
Double Battery, Up to 8800mAh, Support for up to more 10 hours of work time (Optional)
Suitable for adult, pediatric and neonatal patients
Specifications
| Display | 12.1-inch color TFT screen |
|---|---|
| Parameter | SpO2, ECG, NIBP, TEMP, RESP, PR ETCO2 (optional) |
| SpO2 | Range: 0% ~ 100% Accuracy: ±2% at 70 ~ 100% ; <70%, undefined Alarm Range: 50-100% and OFF Averaging: 4,8,16 |
| Pulse rate | Range: 30 ~ 250bpm Accuracy: ±2bpm at 30-250bpm Alarm Range: 30-250BPM and OFF |
| NIBP | Method: Oscillometric Modes: Manual/Auto/Continuous Auto measure Time: Adjustable Measurement range: 10 mmHg ~270 mmHg (adult/pediatric), 10 mmHg ~150mmHg (neonate) Accuracy: meets standard for NIBP accuracy Over pressure safety : Double protection |
| ECG | Lead mode: 3-lead or 5-lead Lead selection: I, II, III, aVR, aVF, V Adult heart rate: 15~300bpm Pediatric/Neonatal heart rate: 15~300bpm ECG waveform: 7 channels Accuracy: ±1 bpm or ±1% S-T segment detection Measurement range: -2.0mV ~ 2.0mV Alarm: Yes, audible and visual alarm, alarm events review |
| Respiration | Method: RA-LL Impedance Heart rate range : Adult: 0 ~ 120 breath/min pediatric/neonatal:0 ~ 150 breath/min Apnea alarm: Yes |
| Temperature | Range: 0 ~ 50 °C Accuracy: ± 0.10 °C Channel: Dual-channel |
| Navigation | Selection control knob |
| Accessories | Standard: Adult SpO2 Probe 5-leads ECG Cable TEMP Probe NIBP Cuff |
| Configuration | Optional: IBP (Invasive Blood Pressure) Built-in-Recorder (be available to 3 channels waveform) (Central Monitoring system) |
Features
