4.3 inches Colorful LCD screen
Injection modes: Rate mode, Time mode, Body weight mode
Applicable for all standard 5, 10, 20, 30, and 50(60) syringes
Adjustable bolus rate during running for continuous injection, no need to stop
Drug library and factory default function
Button Operation history records
Time and calendar display
Qty:
Specifications
| Syringe Size | 5 ml, 10 ml , 20 ml, 30 ml and 50 ml / 60 ml |
|---|---|
| VTBI | 0.1 ml ~ 9999.9 ml |
| Flow Rate | 5 ml: 0.1 ml/h ~ 100 ml/h 10 ml: 0.1 ml/h ~ 200 ml/h 20 ml: 0.1 ml/h ~ 400 ml/h 30 ml: 0.1 ml/h ~ 600 ml/h 50 (60) ml: 0.1 ml/h ~ 1500 ml/h |
| Bolus Rate | 5 ml: 100 ml/h 10 ml: 200 ml/h 20 ml: 400 ml/h 30 ml: 400 ml/h ~ 600 ml/h 50 ml: 400 ml/h ~ 1500 ml/h |
| Safety Classification | Class II, Type BF |
| Infusion Mode | Rate mode, Time mode, Body weight mode |
| KVO Rate | 0.1 ml/h ~ 5.0 ml/h |
| Alarms | Occlusion, near empty, end program Low battery, end battery, AC power off Error 1/ Error 2/ Error 3 Reminder alarm, Pressure sensor error Syringe installation error, Syringe drop off |
| Drug Library | More than 20 drugs listed |
| Occlusion | 0.04 MPa ~ 0.16 MPa LOW, MED, HIGH |
| Rate Mode | 0.1 ~ 1500 ml/h(max value depends on the syringe size) |
| Body Weight Mode | Body weight: 0.1 ~ 300 kgs Drug limit: 0.1 ~ 999.9 mg Volume limit: 0.1 ~ 999.9 ml Dose:0.1 ~ 9999.9 mg (Subject to unit, dosage, liquid, weight and syringe) Unit: mg/kg/h, µg/kg/min |
| Time Mode | Volume limit: 0.1-999.9ml Time: 1-2000min |
| Power Supply, AC | AC: 100 V ~ 240 V 50/60Hz ; 25VA |
| Battery | Rechargeable lithium polymer battery 7.4V, 3000mA |
| Battery Life | 4 hours operation at 25 ml/h after being fully charged |
| Working Temperature | 5℃ ~ 40℃ |
| Relative Humidity | < 80% |
| Atmospheric Pressure | 86 kPa ~ 106 kPa |
| Dimensions | 300 × 139 × 100 mm |
| Weight | 2 kgs |
Features
