Pediatric Fiber Optic Laryngoscope FOLP-1000A features a handle length of 150 mm and a diameter of 30 mm for comfortable handling. With a miller configuration, it presents a straight and rigid blade ideal for pediatric patients. Equipped with a handle developed with a mesh design to prevent slippage caused by operator sweat, ensuring grip. Utilizes a cold light source guided through optical fibres for efficient transmission of light and extended durability.
Qty:
Qty:
Specifications
| Material | Stainless steel |
|---|---|
| Type of Blade | Miller |
| Handle Length | 138 mm |
| Handle Diameter | 30 mm |
| Light Source | Fiber guide blade illumination type |
| Illumination | ≥ 800 Lux |
| Environmental Temperature | 10 to 40℃ |
| Relative Humidity | 30% to 75% |
| Atmospheric Pressure Range | 700 hPa to 1060 hPa |
| Small Blade Size (L × W) | 65×11mm |
| Middle Blade Size (L × W) | 75 × 11mm |
| Large Blade Size (L × W) | 100 × 7.5mm |
| Power Supply | DC 3.0V +5% / -10% |
| Pakaging Dimensions | 490 × 550 × 20 mm |
| Gross Weight | 10 kg |
Features
Designed to be reusable
Smooth and burr-free surface for enhanced safety
Constructed from durable materials for corrosion resistance
Blades crafted from 316 medical stainless steel
Offers bright illumination for clear visualization
Facilitates quick and efficient operation
Separate disinfection of blade and fiber optic
Applications
Pediatric Fiber Optic Laryngoscope is used for examining the larynx and surrounding structures in pediatric patients. It is mostly employed in intubation, airway assessment, foreign body removal, and tracheostomy care.
