Medical Equipment Expert
Hip and knee rehabilitation
Microprocessor controlled operation
Wide motion range
Optimized structural design
Specifications
| Angular range | Angle motion range of knee joint: 0° ~ 125° Angle motion speed range of hip joint: 25° ~ 100° Angle motion speed range of ankle joint: 0° ~ 40° Angle motion speed range: 0.5°/s ~ 2.5°/s Angle motion range of foot plate: ≤ 40° |
|---|---|
| Maximum load | ≥ 60 N |
| Thigh bracket range | 320 mm ~ 500 mm |
| Crus bracket range | 330 mm ~ 450 mm |
| Power | AC 220 / 50 Hz ; < 70W |
Features
Hip and knee rehabilitation
Microprocessor controlled operation
Wide motion range
Optimized structural design
Our continuous passive motion (CPM) unit is a medical device designed to assist in the postoperative rehabilitation of joints, particularly the knee and shoulder. It facilitates controlled, repetitive motion to the affected joint without the patient actively exerting effort. Commonly used after orthopedic surgery, the CPM unit helps prevent joint stiffness, reduces swelling, and promotes healing by providing gentle, continuous movement within a specified range. Adjustable settings allow healthcare professionals to tailor the device to individual patient needs. This non-invasive and automated therapy supports joint recovery, enhances circulation, and contributes to improved joint function, making it an integral part of rehabilitation protocols for conditions such as joint arthroplasty and ligament repairs.
